No-clean flux 808F Introduction

Unibright 808F washable flux is a low solid content washable flux. This unique combination of active systems has excellent wettability on the surface of solder, evenly and reliably removing oxide layers and harmful substances that affect solder, facilitating the formation of interface alloys and bright and full solder joints. After welding, there is very little residue on the board surface and solder joint surface, which is uniform and bright, and has extremely high surface insulation impedance, making it easy to pass ICT testing.

Enquire now

Sample test

No-clean flux 808F Product Features

? Low solid content wash free soldering flux
? Excellent wettability
? The solder joints are bright and full.
? After welding, there is very little residue on the board surface and solder joint surface.
? With extremely high surface insulation impedance, it is easy to pass ICT testing.

No-clean flux 808F Applicable process

Applicable to spray and coating methods.

Apply for product information

No-clean flux 808F Application

? When using wave soldering equipment, it is recommended to preheat the PCB board at a temperature of 90 ℃ -110 ℃ to maximize the effectiveness of the soldering flux.

? During the spray operation of the flux roller, the specific gravity shall be strictly controlled, and the diluent shall be properly added to make it use within the standard specific gravity range (0.80 ± 0.02).

? The soldering solder wave should be flat and minimize the deformation of the PCB board as much as possible, so that the soldering time of each solder point is basically consistent, in order to achieve a more uniform surface effect.

? Pay attention to the adjustment of the nozzle during spray operation, and ensure that the flux is evenly distributed on the PCB surface.

? The compressed air that is degreased, dewatered and cooled shall be used to spray, and the pressure of the compressed air shall be kept stable to avoid the instability of the spray. When the flux becomes muddy or there is suspended solids in the liquid, the flux in the pan shall be removed in time, the flux pan shall be cleaned, and the flux pan shall be replaced.
